Features & Benefits
The feature images used on this page are examples to demonstrate the product benefits and may differ slightly from the actual product.
- PROMOTION
RS6019F3LJ1
60cm Series 9
Integrated Triple Zone Freezer
Ice
- Integrated
-
Smart
Pair with the Integrated Triple Zone Refrigerator for the ultimate kitchen solution – this model features three independent food zones taking cooling flexibility to a new level.*
- Finish
- Panel Ready
- Hinge
- Left hinge
$ 5,999.00
$ 5,499.00
Please enter a postcode to check for stock & delivery information.
Please enter a postcode to check for stock & delivery information.
60cm Series 9
Integrated Triple Zone Freezer
Ice
- Customise with your own kitchen cabinetry or purchase our stainless steel door panel accessory
- Three independent food zones, each with adjustable temperature to store different foods
- Panel ready, flush fit design with 4mm gaps and custom height installation
- Internal ice maker with boost feature for busy times
- Easy-to-use touch-control panel and Wi-Fi capability
*Images for illustration only. No door panels or handles included. Stainless steel versions available for separate purchase to integrate with kitchen cabinetry. Joiner kit sold separately.
Height
1870mm
Width
592mm
Depth
576mm
PERFECT RESULTS
Three Levels Of Freshness
When it comes to optimal food preservation, one temperature does not fit all. Three independent food zones give you full control over the way you care for food. The Freezer zone has adjustable temperature from -21°C to -14°C, while the top two compartments can be converted into a Chill (-1.5°C to 0°C), Soft-Freeze (-10°C to -8°C) or Freezer zone (-21°C to -14°C), to best suit different types of food. Adjust temperature for everyday convenience, or to provide additional chilling capacity for special occasions.
DESIGNED TO FIT
Perfect Fit
These models fit flush, with only 4mm gaps around them and no visible hinges or grilles. Our Integrated models can be seamlessly hidden behind your cabinetry, or you can purchase our stainless steel door panel.
DESIGNED TO FIT
Mix & Match
These modular refrigerators and freezers can be mixed and matched, with different sizes and finishes. Installed side by side or individually throughout the kitchen, you can create a cooling solution to suit your lifestyle. Customise with your own kitchen cabinetry and handles, or purchase our stainless steel door panel and handle options.
PERFECT RESULTS
Chill Mode
Keep ready-to-eat food fresher for longer with Chill mode (-1.5 to 0°C). Chill mode is a perfect solution for everyday life. It keeps meats, poultry and fish as cool as possible without freezing, retaining vital freshness and helps food retain its condition. It’s also great for entertaining. Set one of the top two compartments to Chill mode to quickly bring beverages down to serving temperature.
RESPECT FOR THE PLANET
Clever Energy
ActiveSmart™ Foodcare learns how you live. It is technology that understands how you use your freezer and adjusts temperature, airflow and humidity inside to help keep food fresher for longer.
DESIGNED TO FIT
Simple Installation
Our Integrated products are easy to install, whether you are renovating your kitchen or designing a new one. Adjustable front and rear feet allow for uneven floors alongside adjustable door panels that can be customised to match your kitchen. These models are designed to easily slide into place as separate units – a perfect fit for European design kitchens.
BEAUTIFUL TO USE
Ease Of Use
Using the intuitive touch-sensitive control panel, you can easily adjust the temperature to suit. Beautiful to use, the freezer door is family safe with a soft-close mechanism.
Specifications
- Height
- 1870mm
- Width
- 592mm
- Depth
- 576mm
Accessories (included)
| Accessories (included) Attributes | Value |
|---|---|
| Hinge change (from left hinge to right hinge) | |
| Joiner Kit | AJRS19LR |
Accessories (sold separately)
| Accessories (sold separately) Attributes | Value |
|---|---|
| Door panel set stainless steel | Right & Left hinge RD6019 |
| Handle kit Classic | AHCLRDSF |
| Handle kit Contemporary round, aluminium | AHSRDSF |
| Handle kit Contemporary square fine, aluminium | AHD5RDSF |
| Handle kit Contemporary square fine, black | AHD5RDSFB |
| Handle kit Professional round flush | AHP3RDSF |
| Toe kick stainless steel 1200mm | AKRS12010 |
| Toe kick stainless steel 1800mm | AKRS18010 |
| Toe kick stainless steel 600mm | AKRS06010 |
Capacity
| Capacity Attributes | Value |
|---|---|
| Volume | 303L |
| Volume freezer | 303L |
Consumption
| Consumption Attributes | Value |
|---|---|
| Energy rating | 3.5 star |
| Energy usage | 272kWh/year |
| In-use energy carbon emissions estimate | 177.2kgCO2e/year |
Features
| Features Attributes | Value |
|---|---|
| Adjustable door shelves | 2 |
| Smart Appliance | |
| SmartTouch control panel |
Freezer Features
| Freezer Features Attributes | Value |
|---|---|
| Automatic ice maker | |
| Bottle chill | |
| Door alarm | |
| Fast freeze | |
| Freezer bins | 4 |
| Ice Boost | |
| Ice making rate per day | 1kg |
| LED bin lighting | |
| LED ceiling lighting | |
| LED side lighting |
Installation Dimensions
| Installation Dimensions Attributes | Value |
|---|---|
| Minimum inside width of cabinetry frame | 600mm |
| Minimum internal depth of cabinetry | 600mm |
| Minimum internal height of cabinetry | 1880mm |
Performance
| Performance Attributes | Value |
|---|---|
| ActiveSmart™ Foodcare | |
| Adaptive defrost | |
| Frost free | |
| Inverter controlled compressor | |
| Sabbath mode | |
| Triple evaporator | |
| Variable food modes | Chill, Soft freeze, Freezer |
| Variable temperature zones | 3 |
Power requirements
| Power requirements Attributes | Value |
|---|---|
| Amperage | 10A |
| Supply frequency | 50Hz |
| Supply voltage | 230V |
Product dimensions
| Product dimensions Attributes | Value |
|---|---|
| Depth | 576mm |
| Height | 1870mm |
| Width | 592mm |
Warranty
| Warranty Attributes | Value |
|---|---|
| Parts and labour | 2 years |
| Sealed system parts only | 5 years |
