Features & Benefits
The feature images used on this page are examples to demonstrate the product benefits and may differ slightly from the actual product.
- ARRIVING MAY 2024
DW60U4HI2
Series 9, Integrated Dishwasher
- Series 9
- Integrated
Designed to integrate seamlessly into your cabinetry, this dishwasher delivers superior wash performance and advanced drying.
Panel Ready
- Finish
- Panel Ready
Series 9, Integrated Dishwasher
- Customise with your own front panel and handle to match your kitchen cabinetry
- Eight wash programs from Heavy to Light, including Auto and 60min
- Dry+, Sanitise, Half Load and Intensive modifiers provide extra wash options
- Wi-Fi enabled and works with the Haier Smart Home app for remote control and notifications
*Images for illustration only. No door panels or handles included.
Height
820 - 880mm
Width
597mm
Depth
554mm
DESIGNED TO FIT
Seamless Integration
Customise your dishwasher with a panel and handle matching your cabinetry, for a seamless finish in your kitchen.
PERFECT RESULTS
Advanced Drying
For consistently dry dishes, this dishwasher boasts an advanced drying system that combines fan-assisted drying with an automatic door opening at the cycle's end. By opening to release excess steam, the Auto Door Open Dry feature ensures your dishes emerge dry and ready for immediate use or storage.
PERFECT RESULTS
A Reliable Clean
This dishwasher offers eight wash programs including Auto, which automatically senses the optimal wash settings for your dishes. The three-stage filtration system delivers a superior clean, while the rinse aid indicator reminds you to refill for beautifully clean dishes.
PERFECT RESULTS
Customise Your Wash
The Half Load modifier is ideal for washing smaller loads, ensuring a quicker turnaround for your dishes. The Sanitise function provides extra protection, killing 99.999% of bacteria* in the final rinse, while the Dry+ modifier is perfect for drying plastic. *Certified by CVC for eliminating Helicobacter pylori, H1N1 influenza virus, Poliovirus, Escherichia coli, and Staphylococcus aureus. Sterilisation data source: CVC report RCVC2024-0243.
Beautiful To Use
Quiet Performer
Running at a very low decibel rating, this dishwasher does its job without making a fuss. The combination of clever technology and simple mechanics means greater reliability and superior wash performance, with minimal noise.
RESPECT FOR THE PLANET
Efficient Performance
With a top efficiency rating of grade 1, this dishwasher delivers a powerful wash. Use the Eco wash program for optimal water and energy consumption, or choose when the cycle begins with Delay Start.
BEAUTIFUL TO USE
Flexible Loading
Designed to accommodate 16 place settings with ease, the adjustable rack options offer flexibility for various loads. This dishwasher comes complete with a cutlery tray ideal for smaller utensils, a height-adjustable middle rack, cup holders, and wine glass supports, ensuring it caters to your lifestyle.
Specifications
- Height
- 820 - 880mm
- Width
- 597mm
- Depth
- 554mm
Accessories (included)
| Accessories (included) Attributes | Value |
|---|---|
| Cutlery basket | |
| Kickstrip |
Accessories (sold separately)
| Accessories (sold separately) Attributes | Value |
|---|---|
| Door panel black stainless steel | ADDW60PB |
| Door panel stainless steel | ADDW60PX |
| Handle kit Contemporary square fine, aluminium | AHD5DDDW60S |
| Handle kit Contemporary square fine, black | AHD5DDDW60B |
Capacity and loading
| Capacity and loading Attributes | Value |
|---|---|
| Accommodates round plates up to (lower basket) | 325mm |
| Accommodates round plates up to (top basket) | 220mm (with cutlery tray), 280mm (cutlery tray removed) |
| Adjustable height, foldable cupracks | |
| Easy lift adjustable upper basket | |
| Fold down tines | |
| Fold down wine racks | |
| Full width cutlery/utensil tray | |
| Place settings | 16 |
| Wine glass supports with stemware grippers |
Consumption
| Consumption Attributes | Value |
|---|---|
| Cleaning index | 1.18 |
| Drying index | 1.2 |
Controls
| Controls Attributes | Value |
|---|---|
| Energy saving delay start option of up to 24 hours | |
| Floor light cycle feedback | |
| Internal light | |
| Internal wash selector | |
| Intuitive capacitive touch controls | |
| Keylock | |
| Rinse aid indicator light |
Features
| Features Attributes | Value |
|---|---|
| Air curtain for bench protection | |
| Aquastop | |
| Auto Door Open Dry | |
| Built-in water softener | |
| Fan assisted drying | |
| Flood protection | |
| Fully independent spray arms | |
| Half load option | |
| Motor type | BLDC |
| Three-stage filtration system | |
| Variable wash pressure technology |
Performance
| Performance Attributes | Value |
|---|---|
| Noise emissions | 42dBA |
Power requirements
| Power requirements Attributes | Value |
|---|---|
| Amperage | 10A |
| Supply frequency | 50Hz |
| Supply voltage | 220 - 240V |
Product dimensions
| Product dimensions Attributes | Value |
|---|---|
| Depth | 554mm |
| Height | 820 - 880mm |
| Width | 597mm |
Warranty
| Warranty Attributes | Value |
|---|---|
| Parts and labour | 1 year |
Wash Program Modifiers
| Wash Program Modifiers Attributes | Value |
|---|---|
| Dry + | |
| Half-load | |
| Intensive | |
| Sanitise | |
| Wash modifiers | 4 |
Wash Programs
| Wash Programs Attributes | Value |
|---|---|
| 60 min | |
| Auto | |
| Eco | |
| Glassware | |
| Heavy | |
| Light | |
| Medium | |
| Rinse | |
| Wash programs | 8 |
Water connection
| Water connection Attributes | Value |
|---|---|
| Water pressure | 30kPa - 1000 kPa |
| Water supply | 34" BSP (20mm) Connector Water Inlet Hose |
Resources
Please note: Videos are not for downloading purposes
Download the resource
Download and open pdf in new tab
Design Planning
CAD Downloads
-
2D CAD Files
