48" Series 7 Professional 8 Burner Gas Range, LPG, pdp
RGV3-488L

48" Series 7
Professional 8 Burner Gas Range

LPG

5 out of 5 Customer Rating Reviews
  • Professional
Size plus power. Eight burners deliver powerful 23,500 BTU heat, with two gas ovens for a combined 7.7 cu ft capacity.
48" Series 7
Professional 8 Burner Gas Range
Stainless Steel, LPG
Where to Buy
Finish
Stainless Steel
Fuel Type
LPG
Also available in
starting from $11,149.00
Where to Buy

48" Series 7
Professional 8 Burner Gas Range

LPG

  • Top burner heat of 17,000 BTU, for seriously fast boiling
  • Expansive 7.7 cu ft total oven capacity across two oven cavities
  • Non-tip full-extension shelves in main cavitiy for safe removal of hot dishes
  • Made from quality materials and real stainless steel

LPG gas; requires external gas bottles

Height 353⁄4 - 363⁄4 "
Width 477⁄8 "
Depth 291⁄8 "

RECEIVE UP TO 15% REBATE

Features & Benefits

The feature images used on this page are examples to demonstrate the product benefits and may differ slightly from the actual product.

Generous Capacity
PERFECT RESULTS

Generous Capacity

Featuring a generous total capacity of 7.7 cu ft, with enough room to fit a 32 lb turkey, or to cook several dishes at once.

Cooktop Power
PERFECT RESULTS

Cooktop Power

Sealed Dual Flow Burners™ deliver cooktop power up to 17,000 BTU for seriously fast boiling right down to a precise 140°F full surface simmer with the gentlest of flames.

Cooking Flexibility
BEAUTIFUL TO USE

Cooking Flexibility

The cooktop is designed for easy access to any burner with grates you can smoothly slide pots across. The oven is large enough to hold full size baking sheets.

Easy To Clean
BEAUTIFUL TO USE

Easy To Clean

Cleaning up spills is effortless with the continuous, porcelain basepan. Your cooktop simply needs a quick wipe to keep it looking good as new.

Design Quality
BUILT TO LAST

Design Quality

This range has craftsmanship in every detail, with real stainless steel, cast-iron grates, and titanium coated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful legs to the powerful cooktop, the Range is built to last.

Total Control
BEAUTIFUL TO USE

Total Control

Precise control across high and low settings is delivered through the halo-illuminated cooktop dials.

Specifications

Height
353⁄4 - 363⁄4 "
Width
477⁄8 "
Depth
291⁄8 "

Burner ratings

Burner ratings Attributes Value
Maximum burner power 17000 BTU
Power back centre 13000BTU
Power back centre (2) 13000BTU
Power back left 13000BTU
Power back right 13000BTU
Power centre 15000BTU
Power front centre (2) 15000BTU
Power front left 17000BTU
Power front right 17000BTU
Total cooktop power 116000 BTU

Capacity

Capacity Attributes Value
Shelf positions 5
Total capacity (main oven) 5.3cu ft
Total capacity second oven 2.4cu ft
Usable capacity (main oven) 3.9cu ft

Cleaning

Cleaning Attributes Value
Easy clean porcelain basepan

Controls

Controls Attributes Value
Electric circuit 3 wire
Metal illuminated dials

Gas Requirements

Gas Requirements Attributes Value
Fitting and pipe ½ NPT, min. ⅝" ∅ flex line
Supply Pressure (LPG) 11" to 14" W.C

Oven features

Oven features Attributes Value
Auto re-ignition system
Electronic oven control
Full extension telescopic sliding shelves
Internal light
Titanium coated, illuminated metal dials

Oven functions

Oven functions Attributes Value
Bake
Broil
Convection bake
Slow cook

Oven performance

Oven performance Attributes Value
Main oven - Bake power 21,500 BTU
Main oven - Broil power 19,000 BTU
Secondary oven - Bake power 14,000 BTU

Power requirements

Power requirements Attributes Value
Power supply 120 V, 60 Hz
Service 15 A

Product dimensions

Product dimensions Attributes Value
Depth 29 1⁄8"
Depth (excluding handles) 29 1⁄8"
Height 35 3⁄4 - 36 3⁄4"
Width 47 7⁄8"

Rangetop features

Rangetop features Attributes Value
Sealed range top
Vent trim included

Recommended Back Guards Ventilation

Recommended Back Guards Ventilation Attributes Value
Combustible situation BGRV3-3048H
Non combustible situation BGRV2-3048 / BGRV2-1248
Recommended hood HCB48-12_N (48" Professional Range Hood, Dual Blower)

Safety

Safety Attributes Value
ADA compliant
Full extension telescopic sliding shelves

Secondary oven features

Secondary oven features Attributes Value
3/4 Extension racks 2
Electronic oven control
Internal light

Secondary oven functions

Secondary oven functions Attributes Value
Bake
Convection bake
Number of secondary oven functions 4
Proof
Slow cook
