36" Series 7 Box Chimney Wall Range Hood, pdp
  • END OF LINE
HC36DTXB2_N

36" Series 7
Box Chimney Wall Range Hood

5 out of 5 Customer Rating Reviews
  • Contemporary
The wall chimney range hood has contemporary styling, extracting steam, grease and cooking odors quietly and efficiently.
36" Series 7
Box Chimney Wall Range Hood
Stainless Steel and Glass
Where to Buy
Finish
Stainless Steel and Glass
starting from $1,349.00
Where to Buy

36" Series 7
Box Chimney Wall Range Hood

  • With four fan speeds, select the perfect extraction rate for your cooking
  • Energy-efficient LED lighting to illuminate your cooking surface
  • Powerful 600CFM maximum airflow
Height 233⁄4 - 411⁄16 "
Width 353⁄8 "
Depth 1911⁄16 "

RECEIVE UP TO 15% REBATE

Features & Benefits

The feature images used on this page are examples to demonstrate the product benefits and may differ slightly from the actual product.

BEAUTIFUL TO USE

Quiet And Effective

This vent hood features four fan speeds providing powerful extraction to quickly remove odours and steam. As odors can linger in the kitchen well after cooking is finished, the timer keeps the vent hood working for up to 15 minutes before automatically turning off.

BEAUTIFUL TO USE

Simple Controls

This Fisher & Paykel chimney range hood features a sleek and easy to use soft-touch control panel. This range hood’s LED lights provide bright, warm, energy efficient lighting ensuring the entire cooktop surface is illuminated.

BEAUTIFUL TO USE

Easy Cleaning

The black glass and stainless steel finish is easily wiped clean. Multi-layered, dishwasher safe filters trap grease effectively and can easily be removed for cleaning.

DESIGNED TO FIT

Complementary Design

This wall chimney vent hood's sleek stainless steel finish will complement any contemporary kitchen and is designed to match the rest of Fisher & Paykel's kitchen appliance family.

Specifications

heading.dimensions.header
Height
233⁄4 - 411⁄16 "
Width
353⁄8 "
Depth
1911⁄16 "

Accessories (sold separately)

Accessories (sold separately) Attributes Value
Chimney extension 791774
Light bulb 792579
Recirculation carbon filter 791772
Recirculation diverter 792580

Fan ratings

Fan ratings Attributes Value
Maximum sound rating 67dBA
Speed 3 sound rating 63dBA

Installation and cleaning

Installation and cleaning Attributes Value
Air outlet size 6"
Dishwasher safe filters 3
Ducted Top extraction
Recirculation Optional - top extraction

Performance

Performance Attributes Value
Extraction type Surface
Fan speeds 4
Filter type Mesh
Number of filters 3

Power requirements

Power requirements Attributes Value
Rated current 5.2A
Supply frequency 60Hz
Supply voltage 120V
Total Power 542W

Product dimensions

Product dimensions Attributes Value
Depth 19 11⁄16"
Height 23 3⁄4 - 41 1⁄16"
Width 35 3⁄8"

Product information

Product information Attributes Value
Control type soft-touch button

Ventilation features

Ventilation features Attributes Value
Light type LED

Warranty

Warranty Attributes Value
Parts and labor 2 years
